YASKAWA GA700 Series

8.4 Replace Cooling Fans and Circulation Fans
388 YASKAWA SIEPC71061705H GA700 Series Technical Manual
8.4 Replace Cooling Fans and Circulation Fans
CAUTION! Injury to Personnel. Some fan units are not easily accessible from a standing position. Make sure that you can
safely and comfortably remove and replace the fan. If you try to remove a fan that you cannot easily access, the fan unit can fall
and cause minor to moderate injury.
NOTICE: Use the instructions in this manual to replace the cooling fans. When you do maintenance on the fans, replace all the
fans to increase product life. If you install the fans incorrectly, it can cause damage to the drive.
◆ Cooling Fans and Circulation Fans by Drive Model
Table 8.11 Cooling Fans and Circulation Fans (Three-Phase 200 V Class)
Model Cooling Fan Circulation Fan Procedure Ref.
2004 - 2012 - - - -
2018, 2021 1 - Procedure A 388
2030, 2042 2 - Procedure B 390
2056 - 2082 2 - Procedure C
393
2110 - 2211 2 - Procedure D
395
2257 - 2313 2 - Procedure E
397
2360, 2415 3 1 Procedure F 399
Table 8.12 Cooling Fans and Circulation Fans (Three-Phase 400 V Class)
Model Cooling Fan Circulation Fan
Circuit Board Cooling
Fan
Procedure Ref.
4002 - 4005 - - - - -
4007 - 4012 1 - - Procedure A 388
4018, 4023 2 - - Procedure B 390
4031 - 4060 2 - - Procedure C
393
4075 - 4168 2 - - Procedure D
395
4208 - 4296 2 - - Procedure E
397
4371 2 1 - Procedure F 399
4389 3 1 - Procedure F 399
4453 - 4675 2 1 2 Procedure G 404
◆ Fan Replacement (Procedure A)
DANGER! Electrical Shock Hazard. Do not examine, connect, or disconnect wiring on an energized drive. Before servicing,
disconnect all power to the equipment and wait for the time specified on the warning label at a minimum. The internal capacitor
stays charged after the drive is de-energized. The charge indicator LED extinguishes when the DC bus voltage decreases
below 50 Vdc. When all indicators are OFF, remove the covers before measuring for dangerous voltages to make sure that the
drive is safe. If you do work on the drive when it is energized, it will cause serious injury or death from electrical shock.
CAUTION! Burn Hazard. Do not touch a hot drive heatsink. De-energize the drive, wait for a minimum of 15 minutes, then make
sure that the heatsink is cool before you replace the cooling fans. If you touch a hot drive heatsink, it can burn you.
NOTICE: Use the instructions in this manual to replace the cooling fans. When you do maintenance on the fans, replace all the
fans to increase product life. If you install the fans incorrectly, it can cause damage to the drive.
