4.6 Keypad Operation
182 YASKAWA SIEPC71061705H GA700 Series Technical Manual
8. Push or to select the digit, then push or to change the value.
9. When you are done changing the value, push .
The procedure to set the backlight to turn OFF automatically is complete.
◆ Show Information about the Drive
The procedure in this section shows how to show the drive model, maximum applicable motor output (HD/ND),
rated output current (HD/ND), software version, and the serial number on the keypad.
1. Push [Home] to show the HOME screen.
Note:
• The keypad will [Home] in the top right corner when the HOME screen is active.
• If [Home] is not shown on , push [Back] to show [Home] on .
2. Push [Menu].
3. Push or to select [Diagnostic Tools], then push .
4. Push or to select [Drive Information], then push .
The keypad will show the drive information.
