Startup Procedure and Test Run
4
4.6 Keypad Operation
YASKAWA SIEPC71061705H GA700 Series Technical Manual 181
1. Push (Home) to show the HOME screen.
Note:
• The keypad will show [Home] in the top right corner when the HOME screen is active.
• If [Home] is not shown on , push (Back) to show [Home] on .
2. Push (Menu).
3. Push or to select [Diagnostic Tools], then push .
4. Push or to select [Backlight], then push .
5. Push or to select [ON] or [OFF], then push .
• [ON]: Backlight is always ON
• [OFF]: Backlight turns OFF after set length of time.
6. Push (Setup).
7. Push .
To Next Page
