11.9 F: Options
516 YASKAWA SIEPC71061705H GA700 Series Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F6-71
(03C8)
Dynamic In Assembly
159 Param 4
Sets Configurable Input 4 read from the MEMOBUS register.
0000H
(0000H - FFFFH)
792
F6-72
(081B)
PowerLink Node
Address
Sets the node ID for PowerLink communication.
Note:
Be sure to set an address that is different than all other node addresses. Do not set
this parameter to 0.
0
(0 - 255)
792
◆ F7: Communication Options
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F7-01
(03E5)
IP Address 1
Sets the first octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Address Mode at Startup = Static]:
• Use parameters F7-01 to F7-04 [IP Address 1 to 4] to set the IP Address. Be sure
to set a different IP address for each drive on the network.
• Also set parameters F7-05 to F7-12 [Subnet Mask 1 to 4, Gateway Address 1 to
4].
192
(0 - 255)
792
F7-02
(03E6)
IP Address 2
Sets the second octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Address Mode at Startup = Static]:
• Use parameters F7-01 to F7-04 [IP Address 1 to 4] to set the IP Address. Be sure
to set a different IP address for each drive on the network.
• Also set parameters F7-05 to F7-12 [Subnet Mask 1 to 4, Gateway Address 1 to
4].
168
(0 - 255)
792
F7-03
(03E7)
IP Address 3
Sets the third octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Address Mode at Startup = Static]:
• Use parameters F7-01 to F7-04 [IP Address 1 to 4] to set the IP Address. Be sure
to set a different IP address for each drive on the network.
• Also set parameters F7-05 to F7-12 [Subnet Mask 1 to 4, Gateway Address 1 to
4].
1
(0 - 255)
792
F7-04
(03E8)
IP Address 4
Sets the fourth octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Address Mode at Startup = Static]:
• Use parameters F7-01 to F7-04 [IP Address 1 to 4] to set the IP Address. Be sure
to set a different IP address for each drive on the network.
• Also set parameters F7-05 to F7-12 [Subnet Mask 1 to 4, Gateway Address 1 to
4].
20
(0 - 255)
792
F7-05
(03E9)
Subnet Mask 1
Sets the first octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Address Mode at Startup = Static].
255
(0 - 255)
793
F7-06
(03EA)
Subnet Mask 2
Sets the second octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Address Mode at Startup = Static].
255
(0 - 255)
793
F7-07
(03EB)
Subnet Mask 3
Sets the third octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Address Mode at Startup = Static].
255
(0 - 255)
793
F7-08
(03EC)
Subnet Mask 4
Sets the fourth octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Address Mode at Startup = Static].
0
(0 - 255)
793
F7-09
(03ED)
Gateway Address 1
Sets the first octet of the gateway address of the connected network.
Note:
Set this parameter when F7-13 = 0 [Address Mode at Startup = Static].
192
(0 - 255)
793
