YASKAWA GA700 Series

Specifications
10
10.7 Drive Exterior and Mounting Dimensions
YASKAWA SIEPC71061705H GA700 Series Technical Manual 451
■ 2138, 4089, 4103
Figure 10.6 Dimension Diagram 5
Table 10.30 Three-Phase 200 V Class (IP20/UL Open Type, No Internal EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2
W5
(Maxi
mum)
H1 H2 H3 H4 t1 t2 d
2138
255
(10.04)
450
(17.72)
280
(11.02)
166
(6.54)
114
(4.49)
170
(6.69)
165
(6.50)
12
(0.47)
424
(16.69)
16
(0.63)
29
(1.14)
21
(0.83)
2.3
(0.09)
2.3
(0.09)
M6
21
(46.31)
Table 10.31 Three-Phase 200 V Class (IP20/UL Open Type, with Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2
W5
(Maxi
mum)
H1 H2 H3 H4 t1 t2 d
2138
255
(10.04)
450
(17.72)
280
(11.02)
166
(6.54)
114
(4.49)
170
(6.69)
165
(6.50)
12
(0.47)
424
(16.69)
16
(0.63)
29
(1.14)
21
(0.83)
2.3
(0.09)
2.3
(0.09)
M6
22
(48.51)
Table 10.32 Three-Phase 400 V Class (IP20/UL Open Type, No Internal EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2
W5
(Maxi
mum)
H1 H2 H3 H4 t1 t2 d
4089
255
(10.04)
450
(17.72)
280
(11.02)
166
(6.54)
114
(4.49)
170
(6.69)
165
(6.50)
12
(0.47)
424
(16.69)
16
(0.63)
29
(1.14)
21
(0.83)
2.3
(0.09)
2.3
(0.09)
M6
20
(44.10)
4103
255
(10.04)
450
(17.72)
280
(11.02)
166
(6.54)
114
(4.49)
170
(6.69)
165
(6.50)
12
(0.47)
424
(16.69)
16
(0.63)
29
(1.14)
21
(0.83)
2.3
(0.09)
2.3
(0.09)
M6
24
(52.92)
Table 10.33 Three-Phase 400 V Class (IP20/UL Open Type, with Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2
W5
(Maxi
mum)
H1 H2 H3 H4 t1 t2 d
4089
255
(10.04)
450
(17.72)
280
(11.02)
166
(6.54)
114
(4.49)
170
(6.69)
165
(6.50)
12
(0.47)
424
(16.69)
16
(0.63)
29
(1.14)
21
(0.83)
2.3
(0.09)
2.3
(0.09)
M6
21
(46.31)
4103
255
(10.04)
450
(17.72)
280
(11.02)
166
(6.54)
114
(4.49)
170
(6.69)
165
(6.50)
12
(0.47)
424
(16.69)
16
(0.63)
29
(1.14)
21
(0.83)
2.3
(0.09)
2.3
(0.09)
M6
25
(55.13)
