YASKAWA GA700 Series

10.7 Drive Exterior and Mounting Dimensions
452 YASKAWA SIEPC71061705H GA700 Series Technical Manual
■ 2169, 2211, 4140, 4168
Figure 10.7 Dimension Diagram 6
Table 10.34 Three-Phase 200 V Class (IP20/UL Open Type, No Internal EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2
W5
(Maxi
mum)
H1 H2 H3 H4 t1 t2 d
2169
264
(10.39)
543
(21.38)
335
(13.19)
186
(7.32)
149
(5.87)
190
(7.48)
182
(7.17)
12
(0.47)
516
(20.31)
17.5
(0.69)
28.5
(1.12)
20.5
(0.81)
2.3
(0.09)
2.3
(0.09)
M8
34
(74.97)
2211
264
(10.39)
543
(21.38)
335
(13.19)
186
(7.32)
149
(5.87)
190
(7.48)
182
(7.17)
12
(0.47)
516
(20.31)
17.5
(0.69)
28.5
(1.12)
20.5
(0.81)
2.3
(0.09)
2.3
(0.09)
M8
35
(77.18)
Table 10.35 Three-Phase 200 V Class (IP20/UL Open Type, with Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2
W5
(Maxi
mum)
H1 H2 H3 H4 t1 t2 d
2169
264
(10.39)
543
(21.38)
335
(13.19)
186
(7.32)
149
(5.87)
190
(7.48)
182
(7.17)
12
(0.47)
516
(20.31)
17.5
(0.69)
28.5
(1.12)
20.5
(0.81)
2.3
(0.09)
2.3
(0.09)
M8
35
(77.18)
2211
264
(10.39)
543
(21.38)
335
(13.19)
186
(7.32)
149
(5.87)
190
(7.48)
182
(7.17)
12
(0.47)
516
(20.31)
17.5
(0.69)
28.5
(1.12)
20.5
(0.81)
2.3
(0.09)
2.3
(0.09)
M8
36
(79.38)
Table 10.36 Three-Phase 400 V Class (IP20/UL Open Type, No Internal EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2
W5
(Maxi
mum)
H1 H2 H3 H4 t1 t2 d
4140
264
(10.39)
543
(21.38)
335
(13.19)
186
(7.32)
149
(5.87)
190
(7.48)
182
(7.17)
12
(0.47)
516
(20.31)
17.5
(0.69)
28.5
(1.12)
20.5
(0.81)
2.3
(0.09)
2.3
(0.09)
M8
36
(79.38)
4168
264
(10.39)
543
(21.38)
335
(13.19)
186
(7.32)
149
(5.87)
190
(7.48)
182
(7.17)
12
(0.47)
516
(20.31)
17.5
(0.69)
28.5
(1.12)
20.5
(0.81)
2.3
(0.09)
2.3
(0.09)
M8
37
(81.59)
