YASKAWA GA700 Series

Specifications
10
10.7 Drive Exterior and Mounting Dimensions
YASKAWA SIEPC71061705H GA700 Series Technical Manual 455
Table 10.43 Three-Phase 200 V Class (IP20/UL Open Type, with Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2
W5
(Maxi
mum)
H1 H2 H3 H4 t1 t2 d
2360
440
(17.32)
800
(31.50)
472
(18.58)
254
(10.00)
218
(8.58)
370
(14.57)
370
(14.57)
20
(0.79)
757
(29.80)
28
(1.10)
44
(1.73)
30
(1.18)
4.5
(0.18)
4.5
(0.18)
M12
106
(233.73)
2415
440
(17.32)
800
(31.50)
472
(18.58)
254
(10.00)
218
(8.58)
370
(14.57)
370
(14.57)
20
(0.79)
757
(29.80)
28
(1.10)
44
(1.73)
30
(1.18)
4.5
(0.18)
4.5
(0.18)
M12
112
(246.96)
Table 10.44 Three-Phase 400 V Class (IP20/UL Open Type, No Internal EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2
W5
(Maxi
mum)
H1 H2 H3 H4 t1 t2 d
4371
440
(17.32)
800
(31.50)
472
(18.58)
254
(10.00)
218
(8.58)
370
(14.57)
370
(14.57)
20
(0.79)
757
(29.80)
28
(1.10)
44
(1.73)
30
(1.18)
4.5
(0.18)
4.5
(0.18)
M12
106
(233.73)
4389
440
(17.32)
800
(31.50)
472
(18.58)
254
(10.00)
218
(8.58)
370
(14.57)
370
(14.57)
20
(0.79)
757
(29.80)
28
(1.10)
44
(1.73)
30
(1.18)
4.5
(0.18)
4.5
(0.18)
M12
112
(246.96)
Table 10.45 Three-Phase 400 V Class (IP20/UL Open Type, with Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2
W5
(Maxi
mum)
H1 H2 H3 H4 t1 t2 d
4371
440
(17.32)
800
(31.50)
472
(18.58)
254
(10.00)
218
(8.58)
370
(14.57)
370
(14.57)
20
(0.79)
757
(29.80)
28
(1.10)
44
(1.73)
30
(1.18)
4.5
(0.18)
4.5
(0.18)
M12
111
(244.76)
4389
440
(17.32)
800
(31.50)
472
(18.58)
254
(10.00)
218
(8.58)
370
(14.57)
370
(14.57)
20
(0.79)
757
(29.80)
28
(1.10)
44
(1.73)
30
(1.18)
4.5
(0.18)
4.5
(0.18)
M12
117
(257.99)
■ 4453 - 4675
Figure 10.10 Dimension Diagram 9
