YASKAWA GA700 Series

Specifications
10
10.7 Drive Exterior and Mounting Dimensions
YASKAWA SIEPC71061705H GA700 Series Technical Manual 463
Table 10.66 Three-Phase 400 V Class (IP20/UL Type 1, No Internal EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2
W3
(Maxi
mum)
H0 H1 H2 H3 H5 t1 t2 d
4208
316
(12.44)
915
(36.02)
420
(16.54)
260
(10.24)
160
(6.30)
218
(8.58)
218
(8.58)
16
(0.63)
700
(27.56)
659
(25.94)
28
(1.10)
215
(8.46)
28.5
(1.12)
4.5
(0.18)
4.5
(0.18)
M10
65
(143.33)
4250
316
(12.44)
915
(36.02)
420
(16.54)
260
(10.24)
160
(6.30)
218
(8.58)
218
(8.58)
16
(0.63)
700
(27.56)
659
(25.94)
28
(1.10)
215
(8.46)
28.5
(1.12)
4.5
(0.18)
4.5
(0.18)
M10
67
(147.74)
4296
316
(12.44)
915
(36.02)
420
(16.54)
260
(10.24)
160
(6.30)
218
(8.58)
218
(8.58)
16
(0.63)
700
(27.56)
659
(25.94)
28
(1.10)
215
(8.46)
28.5
(1.12)
4.5
(0.18)
4.5
(0.18)
M10
70
(154.35)
Table 10.67 Three-Phase 400 V Class (IP20/UL Type 1, with Internal EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2
W3
(Maxi
mum)
H0 H1 H2 H3 H5 t1 t2 d
4208
316
(12.44)
915
(36.02)
420
(16.54)
260
(10.24)
160
(6.30)
218
(8.58)
218
(8.58)
16
(0.63)
700
(27.56)
659
(25.94)
28
(1.10)
215
(8.46)
28.5
(1.12)
4.5
(0.18)
4.5
(0.18)
M10
66
(145.53)
4250
316
(12.44)
915
(36.02)
420
(16.54)
260
(10.24)
160
(6.30)
218
(8.58)
218
(8.58)
16
(0.63)
700
(27.56)
659
(25.94)
28
(1.10)
215
(8.46)
28.5
(1.12)
4.5
(0.18)
4.5
(0.18)
M10
68
(149.94)
4296
316
(12.44)
915
(36.02)
420
(16.54)
260
(10.24)
160
(6.30)
218
(8.58)
218
(8.58)
16
(0.63)
700
(27.56)
659
(25.94)
28
(1.10)
215
(8.46)
28.5
(1.12)
4.5
(0.18)
4.5
(0.18)
M10
71
(156.56)
■ 2360, 4371
Figure 10.18 Dimension Diagram 8
Table 10.68 Three-Phase 200 V Class (IP20/UL Type 1, No Internal EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2
W3
(Maxi
mum)
H0 H1 H2 H3 H5 t1 t2 d
2360
444
(17.48)
1045
(41.14)
472
(18.58)
254
(10.00)
218
(8.58)
370
(14.57)
370
(14.57)
18
(0.71)
800
(31.50)
757
(29.80)
28
(1.10)
245
(9.65)
30
(1.18)
4.5
(0.18)
4.5
(0.18)
M12
109
(240.35
)
