Parameter List
11
11.4 A: Initialization Parameters
YASKAWA SIEPC71061705H GA700 Series Technical Manual 479
No.
(Hex.)
Name Description
Default
(Range)
Ref.
A2-14
(0113)
User Parameter 14
Sets the parameter number to be shown for number 14 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
E1-01
(Determined by A1-06)
640
A2-15
(0114)
User Parameter 15
Sets the parameter number to be shown for number 15 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
E1-03
(Determined by A1-06)
640
A2-16
(0115)
User Parameter 16
Sets the parameter number to be shown for number 16 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
E1-04
(Determined by A1-06)
640
A2-17
(0116)
User Parameter 17
Sets the parameter number to be shown for number 17 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
E1-05
(Determined by A1-06)
640
A2-18
(0117)
User Parameter 18
Sets the parameter number to be shown for number 18 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
E1-06
(Determined by A1-06)
640
A2-19
(0118)
User Parameter 19
Sets the parameter number to be shown for number 19 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
E1-09
(Determined by A1-06)
640
A2-20
(0119)
User Parameter 20
Sets the parameter number to be shown for number 20 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
E1-13
(Determined by A1-06)
640
A2-21
(011A)
User Parameter 21
Sets the parameter number to be shown for number 21 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
E2-01
(Determined by A1-06)
640
A2-22
(011B)
User Parameter 22
Sets the parameter number to be shown for number 22 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
E2-04
(Determined by A1-06)
640
A2-23
(011C)
User Parameter 23
Sets the parameter number to be shown for number 23 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
E2-11
(Determined by A1-06)
640
A2-24
(011D)
User Parameter 24
Sets the parameter number to be shown for number 24 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
H4-02
(Determined by A1-06)
640
A2-25
(011E)
User Parameter 25
Sets the parameter number to be shown for number 25 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
L1-01
(Determined by A1-06)
640
A2-26
(011F)
User Parameter 26
Sets the parameter number to be shown for number 26 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
L3-04
(Determined by A1-06)
640
A2-27
(0120)
User Parameter 27
Sets the parameter number to be shown for number 27 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
-
(Determined by A1-06)
640
A2-28
(0121)
User Parameter 28
Sets the parameter number to be shown for number 28 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
-
(Determined by A1-06)
640
A2-29
(0122)
User Parameter 29
Sets the parameter number to be shown for number 29 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32. You can set A2-17 to A2-32 when A2-33 = 0 [User
Parameter Auto Selection = Disabled: Manual Entry Required].
-
(Determined by A1-06)
640
