11.17 U: Monitors
YASKAWA SIEPC71061705H GA700 Series Technical Manual 591
No.
(Hex.)
Name Description MFAO Signal Level
U8-61
(198C)
RemoteDI Monitor 0-7bit
Shows the operation status of Remote DI1 to DI8 as 1 (ON) and 0 (OFF). If Remote DI1 and DI2
are ON, for example, the monitor shows U8-61 = 00000011.
bit 0 : Remote DI1
bit 1 : Remote DI2
bit 2 : Remote DI3
bit 3 : Remote DI4
bit 4 : Remote DI5
bit 5 : Remote DI6
bit 6 : Remote DI7
bit 7 : Remote DI8
No signal output available
U8-62
(198D)
RemoteDI Monitor 8-Fbit
Shows the operation status of Remote DI9 to DI16 as 1 (ON) and 0 (OFF). If Remote DI9 and
DI10 are ON, for example, the monitor shows U8-62 = 00000011.
bit 0 : Remote DI9
bit 1 : Remote DI10
bit 2 : Remote DI11
bit 3 : Remote DI12
bit 4 : Remote DI13
bit 5 : Remote DI14
bit 6 : Remote DI15
bit 7 : Remote DI16
No signal output available
U8-63
(198E)
RemoteDO Monitor 0-7bit
Shows the operation status of Remote DO1 to DO8 as 1 (ON) and 0 (OFF). If Remote DO1 and
DO2 are ON, for example, the monitor shows U8-63 = 00000011.
bit 0 : Remote DO1
bit 1 : Remote DO2
bit 2 : Remote DO3
bit 3 : Remote DO4
bit 4 : Remote DO5
bit 5 : Remote DO6
bit 6 : Remote DO7
bit 7 : Remote DO8
No signal output available
U8-64
(198F)
RemoteDO Monitor 8-Fbit
Shows the operation status of Remote DO9 to DO16 as 1 (ON) and 0 (OFF). If Remote DO9 and
DO10 are ON, for example, the monitor shows U8-64 = 00000011.
bit 0 : Remote DO9
bit 1 : Remote DO10
bit 2 : Remote DO11
bit 3 : Remote DO12
bit 4 : Remote DO13
bit 5 : Remote DO14
bit 6 : Remote DO15
bit 7 : Remote DO16
No signal output available
