Parameter Details
12
12.7 F: Options
YASKAWA SIEPC71061705H GA700 Series Technical Manual 763
If the drive does not detect output pulses from the encoder for longer than the time set in F1-14, the drive will
detect PGo.
Note:
Motor speed and load conditions can cause ov [Overvoltage] and oC [Overcurrent] faults.
F1-17: Deviation 2 Detection Selection
No.
(Hex.)
Name Description
Default
(Range)
F1-17
(03AC)
Deviation 2 Detection
Selection
Usually it is not necessary to change this setting. Sets the number of motor rotations that the drive
will detect more than one Z pulse per rotation to detect dv2.
10
(0 - 100)
When F1-17 = 0, the drive will not detect dv2.
F1-18: Deviation 3 Detection Selection
No.
(Hex.)
Name Description
Default
(Range)
F1-18
(03AD)
Deviation 3 Detection
Selection
Sets the number of rotations necessary to detect conditions that invert the torque reference and
rate of acceleration and cause dv3 [Inversion Detection].
10
(0 - 10)
When the drive detects these two conditions at the same time for the number of times set in F1-18, the drive will
detect dv3.
The torque reference and acceleration are in opposite directions. For example, torque reference is in forward run
and the acceleration is in a negative direction.
The difference between the speed reference and the actual motor speed is more than 30%.
Note:
Reference the setting value for E5-11 [Encoder Z-Pulse Offset] and the δθ value found on the motor nameplate. A usual cause for a dv3
fault is an incorrect E5-11 setting.
Set F1-18 = 0 to disable the function.
F1-19: Deviation 4 Detection Selection
No.
(Hex.)
Name Description
Default
(Range)
F1-19
(03AE)
Deviation 4 Detection
Selection
Sets the number of pulses necessary to cause dv4 [Inversion Prevention Detection].
128
(0 - 5000)
The drive detects a dv4 [Inversion Prevention Detection] faultwhen the pulses in a reverse direction to the speed
reference are input for longer than the time set in F1-19.
Note:
Refer to the E5-11 [Encoder Z-Pulse Offset] value and the Δθ value shown on the motor nameplate. An incorrect E5-11 value will
frequently be the cause of a dv4 fault.
When you use the drive in an application that rotates the motor from the load side in the reverse direction of the speed reference, set
F1-19 = 0.
F1-20: Encoder 1 PCB Disconnect Detect
No.
(Hex.)
Name Description
Default
(Range)
F1-20
(03B4)
Encoder 1 PCB Disconnect
Detect
Sets the function that enables and disables detection of a disconnected encoder connection cable
to cause PGoH [Encoder (PG) Hardware Fault].
1
(0, 1)
0 : Disabled
1 : Enabled
F1-21: Encoder 1 Signal Selection
No.
(Hex.)
Name Description
Default
(Range)
F1-21
(03BC)
Encoder 1 Signal Selection
Sets the number of channels for the signal to the encoder option card.
0
(0, 1)
0 : A Pulse Detection
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
