12.8 H: Terminal Functions
826 YASKAWA SIEPC71061705H GA700 Series Technical Manual
Note:
For information on the comparator function, refer to 66: Comparator1 on page 843 and 67: Comparator2 on page 843.
■ H2-23: Comparator 1 Hysteresis
No.
(Hex.)
Name Description
Default
(Range)
H2-23
(1543)
Comparator 1 Hysteresis
Sets the hysteresis level for comparator 1 as a percentage of the full scale analog output for the
monitor selected in H2-20 [Comparator 1 Monitor Selection].
0.0%
(0.0 - 10.0%)
Note:
For information on the comparator function, refer to 66: Comparator1 on page 843 and 67: Comparator2 on page 843.
■ H2-24: Comparator 1 On-Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H2-24
(1544)
Comparator 1 On-Delay
Time
Sets the on-delay time for comparator 1.
0.0 s
(0.0 - 600.0 s)
Note:
For information on the comparator function, refer to 66: Comparator1 on page 843 and 67: Comparator2 on page 843.
■ H2-25: Comparator 1 Off-Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H2-25
(1545)
Comparator 1 Off-Delay
Time
Sets the off-delay time for comparator 1.
0.0 s
(0.0 - 600.0 s)
Note:
For information on the comparator function, refer to 66: Comparator1 on page 843 and 67: Comparator2 on page 843.
■ H2-26: Comparator 2 Monitor Selection
No.
(Hex.)
Name Description
Default
(Range)
H2-26
(1546)
Comparator 2 Monitor
Selection
Sets the monitor number for comparator 2. Set the x-xx part of the Ux-xx [Monitor]. For example,
set H2-26 = 103 to monitor U1-03 [Output Current].
103
(000 - 999)
Note:
• The configurable monitor changes when the control method changes.
• When you use the terminal in through mode, set this parameter to 000 or 031. You can set the terminal output level from the PLC
through MEMOBUS/Modbus communications or the communication option.
• For information on the comparator function, refer to 66: Comparator1 on page 843 and 67: Comparator2 on page 843.
■ H2-27: Comparator 2 Lower Limit
No.
(Hex.)
Name Description
Default
(Range)
H2-27
(1547)
Comparator 2 Lower Limit
Sets the lower limit detection level for comparator 2 as a percentage of the full scale analog output
for the monitor selected in H2-26 [Comparator 2 Monitor Selection].
0.0%
(0.0 - 300.0%)
Note:
For information on the comparator function, refer to 66: Comparator1 on page 843 and 67: Comparator2 on page 843.
■ H2-28: Comparator 2 Upper Limit
No.
(Hex.)
Name Description
Default
(Range)
H2-28
(1548)
Comparator 2 Upper Limit
Sets the upper limit detection level for comparator 2 as a percentage of the full scale analog output
for the monitor selected in H2-26 [Comparator 2 Monitor Selection].
0.0%
(0.0 - 300.0%)
Note:
For information on the comparator function, refer to 66: Comparator1 on page 843 and 67: Comparator2 on page 843.
