Parameter Details
12
12.11 o: Keypad-Related Settings
YASKAWA SIEPC71061705H GA700 Series Technical Manual 949
To start the drive again after you push to stop operation, turn the external Run command OFF and ON
again.
■ o2-03: User Parameter Default Value
No.
(Hex.)
Name Description
Default
(Range)
o2-03
(0507)
User Parameter Default
Value
Sets the function to keep the settings of changed parameters as user parameter defaults to use
during initialization.
0
(0 - 2)
When you set o2-03 = 1 [Set defaults], the drive saves changed parameter settings as user parameter setting
values in a part of the memory that is isolated from drive parameters.
When you set A1-03 = 1110 [Initialize Parameters = User Initialization] to initialize the drive, the drive resets the
internal parameter setting values to those user parameter setting values.
0 : No change
1 : Set defaults
Saves changed parameter setting values as user default settings.
Set o2-03 = 1 then push to save the user parameter setting values. After the drive saves the setting value, o2-
03 automatically resets to 0.
2 : Clear all
Deletes all of the saved user parameter setting values.
Set o2-03 = 2 then push to clear the user parameter setting values. The drive will automatically reset o2-03 to
0. If you delete the user parameter setting values, you cannot set A1-03 = 1110 to initialize parameters.
■ o2-04: Drive Model (KVA) Selection
No.
(Hex.)
Name Description
Default
(Range)
o2-04
(0508)
Drive Model (KVA)
Selection
Sets the Drive Model code. Set this parameter after replacing the control board.
Determined by the drive
(-)
NOTICE: Set o2-04 [Drive Model (KVA) Selection] correctly. If you set this parameter incorrectly, it will decrease drive
performance, cause the protection function to operate incorrectly, and cause damage to the drive.
Note:
When the setting value of o2-04 changes, related parameter setting values also change. Refer to Defaults by Drive Model and Duty
Rating ND/HD on page 602 for more information.
These tables list the relation between o2-04 setting values and drive models.
Table 12.79 Three-Phase 200 V Class
Drive Model o2-04 Setting
2004 62
2006 63
2010 65
2012 66
2018 67
2021 68
2030 6A
2042 6B
2056 6D
2070 6E
Drive Model o2-04 Setting
2082 6F
2110 70
2138 72
2169 73
2211 74
2257 75
2313 76
2360 77
2415 78
Table 12.80 Three-Phase 400 V Class
Drive Model o2-04 Setting
4002 92
4004 93
Drive Model o2-04 Setting
4005 94
4007 95
