2. Logic Elements and Logic Array Blocks
in Cyclone IV Devices
This chapter contains feature definitions for logic elements (LEs) and logic array
blocks (LABs). Details are provided on how LEs work, how LABs contain groups of
LEs, and how LABs interface with the other blocks in Cyclone
®
IV devices.
Logic Elements
Logic elements (LEs) are the smallest units of logic in the Cyclone IV device
architecture. LEs are compact and provide advanced features with efficient logic
usage. Each LE has the following features:
■ A four-input look-up table (LUT), which can implement any function of four
variables
■ A programmable register
■ A carry chain connection
■ A register chain connection
■ The ability to drive the following interconnects:
■ Local
■ Row
■ Column
■ Register chain
■ Direct link
■ Register packing support
■ Register feedback support
