Chapter 1: Cyclone IV FPGA Device Family Overview 1–7
Cyclone IV Device Family Speed Grades
March 2016 Altera Corporation Cyclone IV Device Handbook,
Volume 1
Cyclone IV Device Family Speed Grades
Tab le 1 –5 lists the Cyclone IV GX devices speed grades.
Tab le 1 –6 lists the Cyclone IV E devices speed grades.
Table 1–5. Speed Grades for the Cyclone IV GX Device Family
Device F169 F324 F484 F672 F896
EP4CGX15 C6, C7, C8, I7 — — — —
EP4CGX22 C6, C7, C8, I7 C6, C7, C8, I7 — — —
EP4CGX30 C6, C7, C8, I7 C6, C7, C8, I7 C6, C7, C8, I7 — —
EP4CGX50 — — C6, C7, C8, I7 C6, C7, C8, I7 —
EP4CGX75 — — C6, C7, C8, I7 C6, C7, C8, I7 —
EP4CGX110 — — C7, C8, I7 C7, C8, I7 C7, C8, I7
EP4CGX150 — — C7, C8, I7 C7, C8, I7 C7, C8, I7
Table 1–6. Speed Grades for the Cyclone IV E Device Family
(1), (2)
Device E144 M164 M256 U256 F256 F324 U484 F484 F780
EP4CE6
C8L, C9L, I8L
C6, C7, C8, I7,
A7
——I7N
C8L, C9L, I8L
C6, C7, C8, I7,
A7
—— — —
EP4CE10
C8L, C9L, I8L
C6, C7, C8, I7,
A7
——I7N
C8L, C9L, I8L
C6, C7, C8, I7,
A7
—— — —
EP4CE15
C8L, C9L, I8L
C6, C7, C8, I7
I7NC7N, I7NI7N
C8L, C9L, I8L
C6, C7, C8, I7,
A7
——
C8L, C9L, I8L
C6, C7, C8, I7,
A7
—
EP4CE22
C8L, C9L, I8L
C6, C7, C8, I7,
A7
——I7N
C8L, C9L, I8L
C6, C7, C8, I7,
A7
—— — —
EP4CE30 — — — — — A7N —
C8L, C9L, I8L
C6, C7, C8, I7,
A7
C8L, C9L, I8L
C6, C7, C8, I7
EP4CE40 — — — — — A7N I7N
C8L, C9L, I8L
C6, C7, C8, I7,
A7
C8L, C9L, I8L
C6, C7, C8, I7
EP4CE55 — — — — — — I7N
C8L, C9L, I8L
C6, C7, C8, I7
C8L, C9L, I8L
C6, C7, C8, I7
EP4CE75 — — — — — — I7N
C8L, C9L, I8L
C6, C7, C8, I7
C8L, C9L, I8L
C6, C7, C8, I7
EP4CE115 — — — — — — —
C8L, C9L, I8L
C7, C8, I7
C8L, C9L, I8L
C7, C8, I7
Notes to Table 1–6:
(1) C8L, C9L, and I8L speed grades are applicable for the 1.0-V core voltage.
(2) C6, C7, C8, I7, and A7 speed grades are applicable for the 1.2-V core voltage.
