1–6 Chapter 1: Cyclone IV FPGA Device Family Overview
Package Matrix
Cyclone IV Device Handbook, March 2016 Altera Corporation
Volume 1
Table 1–4 lists Cyclone IV GX device package offerings, including I/O and transceiver counts.
Table 1–4. Package Offerings for the Cyclone IV GX Device Family
(1)
Package F169 F324 F484 F672 F896
Size (mm) 14 × 14 19 × 19 23 × 23 27 × 27 31 × 31
Pitch (mm) 1.0 1.0 1.0 1.0 1.0
Device
User I/O
LVDS
(2)
XCVRs
User I/O
LVDS
(2)
XCVRs
User I/O
LVDS
(2)
XCVRs
User I/O
LVDS
(2)
XCVRs
User I/O
LVDS
(2)
XCVRs
EP4CGX15 72 25 2 — — — — — — — — — — — —
EP4CGX22 72 25 2 150 64 4 — — — — — — — — —
EP4CGX30 72 25 2 150 64 4 290 130 4 — — — — — —
EP4CGX50 — — — — — — 290 130 4 310 140 8 — — —
EP4CGX75 — — — — — — 290 130 4 310 140 8 — — —
EP4CGX110 — — — — — — 270 120 4 393 181 8 475 220 8
EP4CGX150 — — — — — — 270 120 4 393 181 8 475 220 8
Note to Table 1–4:
(1) Use the Pin Migration View window in Pin Planner of the Quartus II software to verify the pin migration compatibility when you perform device migration. For more
information, refer to the I/O Management chapter in volume 2 of the Quartus II Handbook.
(2) This includes both dedicated and emulated LVDS pairs. For more information, refer to the I/O Features in Cyclone IV Devices chapter.
