implements either a high-speed deserializer receiver or a high-speed serializer
transmitter. There is a list of parameters in the ALTLVDS megafunction that you can
set to customize your SERDES based on your design requirements. The megafunction
is optimized to use Cyclone IV devices resources to create high-speed I/O interfaces
in the most effective manner.
1 When you use Cyclone IV devices with the ALTLVDS megafunction, the interface
always sends the MSB of your parallel data first.
f For more details about designing your high-speed I/O systems interfaces using the
ALTLVDS megafunction, refer to the ALTLVDS Megafunction User Guide and the
Quartus II Handbook.
Document Revision History
Tab le 6 –1 2 lists the revision history for this chapter.
Table 6–12. Document Revision History (Part 1 of 2)
Date Version Changes
March 2016 2.7
■ Updated Table 6–5 and Table 6–9 to remove support for the N148 package.
May 2013 2.6
■ Updated Table 6–2 by adding Note (9).
■ Updated Table 6–4 and Table 6–8 to add new device options and packages.
February 2013 2.5 Updated Table 6–4 and Table 6–8 to add new device options and packages.
October 2012 2.4
■ Updated “I/O Banks” and “High Speed Serial Interface (HSSI) Input Reference Clock
Support ” sections.
■ Updated Table 6–3 and Table 6–5.
■ Updated Figure 6–10.
November 2011 2.3
■ Updated “Differential SSTL I/O Standard Support in Cyclone IV Devices” and
“Differential HSTL I/O Standard Support in Cyclone IV Devices” sections.
■ Updated Table 6–1, Table 6–8, and Table 6–9.
■ Updated Figure 6–1.
December 2010 2.2
■ Updated for the Quartus II software version 10.1 release.
■ Added Cyclone IV E new device package information.
■ Added “Clock Pins Functionality” section.
■ Updated Table 6–4 and Table 6–8.
■ Minor text edits.
July 2010 2.1
■ Updated “Cyclone IV I/O Elements”, “Programmable Pull-Up Resistor”, “I/O Banks”,
“High-Speed I/O Interface”, and “Designing with BLVDS” sections.
■ Updated Table 6–6 and Table 6–7.
■ Updated Figure 6–19.
