Altera Cyclone IV - IOE Programmable Delay

1–34 Chapter 1: Cyclone IV Device Datasheet
Switching Characteristics
Cyclone IV Device Handbook, December 2016 Altera Corporation
Volume 3
IOE Programmable Delay
Table 1–40 and Table 1–41 list the IOE programmable delay for Cyclone IV E 1.0 V
core voltage devices.
Table 1–40. IOE Programmable Delay on Column Pins for Cyclone IV E 1.0 V Core Voltage Devices
(1), (2)
Parameter Paths Affected
Number
of
Setting
Min
Offset
Max Offset
UnitFast Corner Slow Corner
C8L I8L C8L C9L I8L
Input delay from pin to
internal cells
Pad to I/O
dataout to core
7 0 2.054 1.924 3.387 4.017 3.411 ns
Input delay from pin to
input register
Pad to I/O input
register
8 0 2.010 1.875 3.341 4.252 3.367 ns
Delay from output register
to output pin
I/O output
register to pad
2 0 0.641 0.631 1.111 1.377 1.124 ns
Input delay from
dual-purpose clock pin to
fan-out destinations
Pad to global
clock network
12 0 0.971 0.931 1.684 2.298 1.684 ns
Notes to Table 1–40:
(1) The incremental values for the settings are generally linear. For the exact values for each setting, use the latest version of the Quartus II software.
(2) The minimum and maximum offset timing numbers are in reference to setting 0 as available in the Quartus II software.
Table 1–41. IOE Programmable Delay on Row Pins for Cyclone IV E 1.0 V Core Voltage Devices
(1), (2)
Parameter Paths Affected
Number
of
Setting
Min
Offset
Max Offset
UnitFast Corner Slow Corner
C8L I8L C8L C9L I8L
Input delay from pin to
internal cells
Pad to I/O
dataout to core
7 0 2.057 1.921 3.389 4.146 3.412 ns
Input delay from pin to
input register
Pad to I/O input
register
8 0 2.059 1.919 3.420 4.374 3.441 ns
Delay from output register
to output pin
I/O output
register to pad
2 0 0.670 0.623 1.160 1.420 1.168 ns
Input delay from
dual-purpose clock pin to
fan-out destinations
Pad to global
clock network
12 0 0.960 0.919 1.656 2.258 1.656 ns
Notes to Table 1–41:
(1) The incremental values for the settings are generally linear. For the exact values for each setting, use the latest version of the Quartus II software.
(2) The minimum and maximum offset timing numbers are in reference to setting 0 as available in the Quartus II software.
