3. Memory Blocks in Cyclone IV Devices
Cyclone
®
IV devices feature embedded memory structures to address the on-chip
memory needs of Altera
®
Cyclone IV device designs. The embedded memory
structure consists of columns of M9K memory blocks that you can configure to
provide various memory functions, such as RAM, shift registers, ROM, and FIFO
buffers.
This chapter contains the following sections:
■ “Memory Modes” on page 3–7
■ “Clocking Modes” on page 3–14
■ “Design Considerations” on page 3–15
Overview
M9K blocks support the following features:
■ 8,192 memory bits per block (9,216 bits per block including parity)
■ Independent read-enable (
rden
) and write-enable (
wren
) signals for each port
■ Packed mode in which the M9K memory block is split into two 4.5 K single-port
RAMs
■ Variable port configurations
■ Single-port and simple dual-port modes support for all port widths
■ True dual-port (one read and one write, two reads, or two writes) operation
■ Byte enables for data input masking during writes
■ Two clock-enable control signals for each port (port A and port B)
■ Initialization file to pre-load memory content in RAM and ROM modes
November 2011
CYIV-51003-1.1
