3-50 PN: 10580-00343 Rev. H S820E UG
3-8 Trace Cable and Antenna Measurements
.
Figure 3-31. Trace Memory Used to Compare Return Loss of 2 Cables
Example A. Sample Traces
Example B. Trace - Memory
Example C. Trace + Memory
Memory Trace
(Purple)
Live Trace
(Yellow)
