S820E UG PN: 10580-00343 Rev. H 10-29
File Management 10-11 File Menu
Save Menu
Key Sequence: File (7) > Save
File > Save
Save: Press this submenu key to display the “Save
Dialog Box” on page 10-4. Site Master files can be saved
to internal memory or to a USB flash drive. The saved
Measurement, Setup, or Screen shot file can be named
by using the touchscreen keyboard. By default,
measurements are saved to internal memory. The save
destination is set using the Set Location submenu key.
Refer to “Set the Save Location” on page 10-5.
By default, the Filetype is Measurement. Press this
button to display the Filetype menu.
Save > Filetype
Filetype: Press this button to display the File Type
menu:
Measurement (.dat)
Setup (.stp)
ScreenShot (.png)
S2P (.s2p)
Text (.txt)
CSV (.csv)
The selectable file types are different in Video Inspection
Probe (VIP) mode. See Figure 15-7 on page 15-8.
Figure 10-29.Save Menu (1 of 3)
Save
Save
Measurement
Filetype:
Setup
(.stp)
Measurement
(.dat)
ScreenShot
(.png)
File Type
To Next Page
