11-8 System Menu System Operations
Status Menu
Key Sequence: System (8) > System Info > Status
Pressing the Anritsu logo on the touchscreen also displays this Status menu.
(Refer to item 1 in Figure 2-6 on page 2-14.)
Status
Instrument Info: Displays the instrument model, installed
options, serial number, UUID.
HW Info: Displays information on main board temperature
(internal temperature), remaining battery charge, system
voltage, and ID information for various components.
SW Info: Press this submenu key to display the version of
various software components.
Connectivity Info: Press this submenu key to display the
Ethernet IP Address and MAC address of the instrument.
Save to File: Press Save to File to create a text file of the
instrument status. The file is saved to internal memory and
labeled S820EStatus#X.txt. The .txt file can be copied
to a USB memory device and viewed on a PC with a text
reader or word processor.
Figure 11-14. Status Menu
SW Info
Save To File
HW Info
Instrument Info
Connectivity
Info
