S820E UG PN: 10580-00343 Rev. H 14-1
Chapter 14 — Anritsu easyTest Tools
14-1 Introduction
easyTest Tools allows you to create a test sequence (.ett) file on a PC. The
file can be copied to the S820E via a USB memory stick and opened from the
Menu screen by pressing the easyTest icon.
easyTest Tools files can:
• Display custom user images on the screen of the S820E. Images may
include connection diagrams or procedure steps. easyTest supports a
variety of image types including .jpg, .bmp, and .png.
• Set instrument parameters to a specific state including measurement
type, frequency and amplitude settings, limit lines, and markers. This
is accomplished by including a previously-saved instrument setup in
the easyTest Tool file.
• Prompt you with a message at the top of the display. While the
message is displayed, the instrument can be unlocked for prompts that
require user action. An example message is “Press the Autoscale button
to zoom in on the trace”.
• Include automatic or manual saving and naming of measurements or
Note
Screen images in this User Guide are illustrations of typical
instrument features. Some images may include instruments other
than the Site Master S820E. Traces and other display features
may differ from the screen displays of your instrument.
