Calibration, CAA 4-3 Calibration Procedures
4-3 Calibration Procedures
In Cable and Antenna Analyzer Mode, calibration is required when the “Cal
Status Off” or “Cal Status --” message is displayed, or when the test port cable
or adapters have been changed. The following sections describe how to
perform calibrations.
Calibration Procedure
1. Press the Freq/Dist main menu key and enter the appropriate frequency
range.
2. Press the Calibration main menu key, then press Start Calibration.
3. Press Cal Setup to make changes to the setup as needed (refer to
Section 4-2 “Calibration Setup” on page 4-3).
4. Press Measure and follow the on screen instructions (see Figure 4-10
on page 4-16).
5. Verify that the calibration has been completed by confirming that the
Cal Status message is now displaying “Cal Status OK (xxxx)”, where
“xxxx” indicates the Cal Type. The calibration correction factor will
now be applied to the measurements.
6. The calibration factors can be turned Off with the Cal Correction button.
The calibration coefficients are saved and can be reapplied by setting
Cal Correction back to On.
Note
If a Test Port Extension Cable is to be used (this is
recommended), then it must be connected to the Site Master
before calibration.
