Anritsu S820E - Calibration Menu

S820E UG PN: 10580-00343 Rev. H 7-19
Calibration, VNA 7-5 Calibration Menu
7-5 Calibration Menu
Key Sequence: Calibration
Calibration
Start Calibration: Opens the Calibration dialog box
(Figure 7-13 on page 7-21). Two menu buttons are
displayed in the Calibration dialog box.
Thru Update: Opens the Calibration dialog box to allow
calibrating the Thru component without repeating the
entire calibration sequence. This key is displayed only
after a calibration with a Thru component.
Cal Info: Displays the Calibration Information table
showing the current and active calibration settings. See
Figure 7-3 on page 7-5.
Interpolation (On Off): Press this submenu key to
toggle Interpolation On or Off. After performing a
Standard calibration, you can turn Interpolation On and
then change the frequency range (smaller) or change the
number of data points. For more details, refer to
“Interpolation” on page 7-20.
Cal Correction (On Off): Press this submenu key to
toggle Cal Correction On or Off. Turn Cal Correction On
to apply the correction factor to the current measurement.
For more details, refer to “Cal Correction” on page 7-20.
Figure 7-12. Calibration Menu
Calibration
alibration
a
libration
bration
bato
bato
Start
Calibration
Cal Correction
On O
Cal Info
Interpolation
al
C
o
rrecti
on
O
n
O

n
ter
p
o
l
atio
n
On O
Thru Update
C
r
C
C
r
C
u
Ca
u
a
u
a
l In
fo
u
Updat
e
