Displayed Measurements
Select the forward and reverse measurements to display in the graph area
(the analog graph always shows the forward measurement). Select Forward
Display and/or Reverse Display under the Display main menu and choose a
measurement. See Figure 9-8 for examples of measurement combinations.
Refer to “Forward Menu” on page 9-28 and “Reverse Menu” on page 9-29 for
additional information.
Figure 9-11. Forward and Reverse Measurement Combinations
