11-12 PN: 10580-00343 Rev. H S820E UG
11-6 Screen Shot Capture System Operations
11-6 Screen Shot Capture
The Site Master can capture a bit mapped image of the display in Portable
Network Graphics (.png) format using the Camera icon, .
The file is automatically named based on the instrument model and
measurement type. Screen shot files are saved to the instrument’s internal
memory in the ScrnShots folder (Drive : Internal | ScrnShots).
The number keypad can be used to save a screen shot by pressing and holding
the Shift key while then pressing (one at a time) the period (.) key, then the
+/– key.
The look of the saved screen shot is set in this location: System (8) > System
Setups > Display/Audio > ScrnShot Settings. Refer to the “Display/Audio
Menu” on page 11-21 for details. Figure 11-9 on page 11-13 is an example of
the same measurement saved with different screen shot settings.
Note
Measurements can also be saved as screen shots using the
File (7) menu then Save and setting the Filetype to ScreenShot.
Screen shots saved through the File Save Menu will be saved in
the current save directory. Refer to Chapter 10 for additional
information.
