S820E UG PN: 10580-00343 Rev. H 2-15
Instrument Overview 2-5 Touchscreen Display Overview
Main Menu Keys
The main menu keys are horizontally arranged along the lower edge of the
touchscreen. The main menu key functions change based on the instrument
mode. The instrument mode is set with the Mode (9) key, the Menu key, or
the mode selector icon (icon not available in Classic mode). The main
menu keys generate function-specific submenus.
Submenu Keys
These submenu keys are arranged along the right-hand edge of the
touchscreen. The submenu keys change based on the selected Main Menu or
Keypad Menu key.
Several submenus may be displayed in the submenu block area. Press any
collapsed submenu title to expand the submenu and display the submenu
buttons. Press one of the submenu buttons to make a selection or set a
parameter.
6. Collapsed submenu. Pressing a collapsed submenu causes it to expand
as shown in row 5. Refer to “Submenu Keys” on page 2-15.
7. Active trace sweeping between Start Frequency (F1) and Stop Frequency
(F2).
8. Marker Table. Refer to “Markers” on page 3-40.
9. Marker 1.
10. Main Menu keys with Measurement selected. Refer to “Main Menu Keys”
on page 2-15.
11. Warning and Status Area.
12. User-defined Shortcuts. Refer to “Menu Key” on page 2-5. Not displayed
in Classic Mode.
13. Graph, a 10 x 10 grid showing the active trace.
14. Instrument Settings Summary provides a selection of Measurement
Information pertaining to the current, active trace, or traces. May also be
used as a touchscreen shortcut to submenus.
Figure 2-6. Site Master Display Overview (2 of 2)
