Windowing Menu
Key Sequence: Freq/Dist > DTF Setup > Windowing
Rectangular: Rectangular Windowing shows the highest
side lobe levels (worst) and the greatest main lobe resolution
(best).
Nominal Side Lobe: Nominal Side Lobe Windowing shows
less side lobe levels than Rectangular Windowing (good) but
lower main lobe resolution (very good).
Low Side Lobe: Low Side Lobe Windowing shows less side
lobe levels than Nominal Windowing (very good) but lower
main lobe resolution (good).
Minimum Side Lobe: Minimum Side Lobe Windowing
shows the lowest side lobe levels (best) but the least main
lobe resolution (worst).
Figure 3-39. Windowing Menu
