S820E UG PN: 10580-00343 Rev. H 10-9
File Management 10-4 Save Files
Choose the File Name
Default Name
The Site Master adds a default file name based on the instrument model and
current measurement type.
RL = Return Loss
DTF-RL = Distance to Fault Return Loss
CL = Cable Loss
VSWR = Voltage Standing Wave Ratio
DTF-VSWR = Distance to Fault Voltage Standing Wave Ratio
TR2P = Transmission (2-Port)
TRES = Transmission (Ext. Sensor)
SC = Smith Chart
PH = 1-Port Phase
HiPM = High Accuracy Power Meter
Additional measurements of the same type will have a number appended to
the file name (#1, #2, and so forth).
Press Save or Enter to save the file.
Note
A Filetype extension (Figure 10-5) is automatically added to the
Filename based on the chosen Filetype.
