S820E UG PN: 10580-00343 Rev. H 10-3
File Management 10-3 File Types
10-3 File Types
Filename extensions that are used in the Site Master S820E:
• *.dat for Cable and Antenna measurement files
• *.hipm for High Accuracy Power Meter measurement files
• *.svna for VNA mode measurement files
• *.s2p (SnP) for VNA mode measurement files:
Real/Imag
Lin Mag/Phase
Log Mag/Phase
• *.ett for easyTest files
• *.stp for Setup files
• *.png for Screen Shot files
• *.csv text file with Comma Separated Values (CSV), for saving
formatted data
• *.txt for saving Status information and Self Test results
• *.vipi for Video Inspection Probe measurement files
Note
S2P is a standard ASCII text file format that is used for scattering
parameters from a 2-Port measurement. This is a subset of SnP
(where n equals the number of ports). An S2P file can be used as
input for signal analysis.
The CSV and Text files contain setup information and final
formatted data that are shown on the instrument display screen.
This file information includes any post-processing that was done
on the data (smoothing, trace math, and so forth). These files
contain the data for any traces that are displayed, including the
memory traces. They also contain the markers that are turned on
when the file is saved.
