10-10 PN: 10580-00343 Rev. H S820E UG
10-4 Save Files File Management
Custom Name
Replace the default file name using the on screen keyboard or the number
keypad. The highlighted filename (blue background) is ready for replacement.
Tap the key (or the Shift button on the instrument keypad) for
UPPERCASE letters. The key (row 7 in Figure 10-1 on page 10-4) will
display commonly used symbols, delimiters, and numbers.
Use the Left or Right Arrow keys to move the text cursor within the filename
characters. The key deletes the character directly to the left of the
cursor.
EZ Name Matrix
The EZ Name Matrix buttons display the EZ Name Grids which allows
contractors and field personnel to save time entering filenames when they are
making measurements.
Often carriers require filenames to be reported in special conventions
including site number, sector information, color coding, measurement type,
termination device, and frequency information. Set up the buttons in this
matrix to quickly enter the required file name.
Using the touchscreen, in the File Mgmnt menu, press Rename. Then press
either EZ Name Page 1 or EZ Name Page 2 (shown in Figure 10-6
on page 10-11) to open the EZ Name matrix keyboards.
Note
The EZ Name Separator Keys shown in Figure 10-6 can be used
to automatically insert a separator each time a Matrix button is
pressed.
The top button toggles the separator on or off. The button below
allows you to choose between using a dash “-” or an underscore
“_” as the separator.
Naming Examples:
Separator Off:
Site AAlphaColor CodeRLShort700
Separator On:
Site A-Alpha-Color Code-RL-Short-700
or
Site A_Alpha_Color Code_RL_Short_700
