Anritsu S820E - Marker Menu

S820E UG PN: 10580-00343 Rev. H 3-63
Cable and Antenna Measurements 3-14 Marker Menu
3-14 Marker Menu
Key Sequence: Marker
Marker Setup
Select (1–8) M#: Press to turn on a marker (1 to 8) and
selects which marker is active (green half circle). Current
active marker is displayed on the button (M1).
Edit: Press to change the position of the active marker using
the Up/Down Arrow keys, rotary knob or the keypad.
Type: Sets the current active marker as a reference
(standard) marker or a delta marker to Marker 1. Marker 1 is
always a reference marker.
M# (On Off): Toggles the display of the active marker on or
off. When off the location of the marker is stored.
Display (Mkr + Table, Mkr Only, Off): Press to open
display options.
Mkr+Table: Displays both the markers that are on
and marker table.
Mkr Only: Displays markers that are on, hides the
marker table.
Off: Hides all markers and the marker table.
Marker Preset: Turns off all markers except for Marker 1.
Sets Marker 1 location to the middle of the sweep.
Figure 3-42. Marker Menu (1 of 2)
Marker
Type
Ty
p
e
Ref Delta
Display
Mkr + Table
Edit
Marker Setup
Marker Preset
M1
Di
Mk
r
i
sp
l
a
y
+
Ta
bl
e
M1
On O
Select (1-8)
M1
Ed
i
t
p
e
ct
(
1-8
)
M1
