6-16 Sweep Menu 2 VNA Mode
6-16 Sweep Menu 2
Power Setup
Key Sequence: Sweep (3) > Power Setup
RF Pwr In Hold
This setting determines if the RF output power at the RF Out/Reflect In port
stays On or is turned Off when the instrument Run/Hold setting is toggled to
Hold. To turn off RF power at the port when the instrument is placed in Hold
mode and is not sweeping, set RF Pwr In Hold to Off. Power at the port is
resumed when the Run/Hold setting is toggled back to Run. This is useful
when you may not want a signal radiating out of the port at all times.
Power Setup
Source Power
High Low: This toggles the source power between High
and Low. Refer to “Calibration Data and Indications”
on page 7-2.
RF Pwr In Hold
On Off: Sets the RF Output power to be left On or to be
turned Off when Run/Hold is toggled to Hold. Refer to
“RF Pwr In Hold” for details.
Figure 6-29. Sweep Menu – Power Setup
Sweep Setup
RF Pwr In Hold
On O
Source Power
RF Pwr In H
o
l
On
O

S
ou
rce P
o
we
High Low
Port 2 Cong
Port 1 Cong
Power Setup
