Sweep Setup
Key Sequence: Sweep (3) > Sweep Setup
Sweep Setup
Data Points: Sets the number of data points in the sweep.
This value can be set to any integer value between 2 and
4001.
Run/Hold
Run Hold: Toggles between Run and Hold. When in Hold
mode, pressing this key provides a trigger to initiate a sweep.
When in the Run mode, pressing this key pauses the sweep.
Sweep Trigger: This displays the “Sweep Trigger Menu”
on page 6-36. The mode is displayed on the submenu key.
Continuous is the default.
RF Immunity
High Low: The instrument defaults to RF Immunity Low.
IFBW: Press this submenu key to display the IFBW
selection box. Highlight one of the 13 choices. Refer to
“IFBW” on page 6-37.
Sweep Averaging: Press this submenu key to set the
number of sweeps to average at each sweep point
(1 to 1000). Use the number keypad, the Up/Down Arrow
keys, or the rotary knob, then press Enter.
Figure 6-27. Sweep Menu – Sweep Setup
