1-6 PN: 10580-00343 Rev. H S820E UG
1-5 Additional Documents General Information
Calibration Requirements
The Cable and Antenna Analyzer requires user-performed calibration before
making measurements. Calibration can be quickly and easily performed
using several calibration options. Calibration components are sold separately.
Refer to Chapter 4, “Calibration, CAA” for additional information.
1-5 Additional Documents
The following documents provide additional information about the
Site Master S820E Cable and Antenna Analyzer.
• Site Master S820E Technical Data Sheet (11410-00650). Includes
general specifications, detailed measurement specifications for all
available measurement modes, ordering information, and a list of
available accessories.
• Site Master S820E Programming Manual (10580-00344). Includes an
overview of the compatible SCPI commands used to remotely access the
Site Master S820E.
• Site Master S820E Product Brochure (11410-00726). Includes an
overview of the of the Site Master S820E instrument, ordering
information, and accessories information.
• Site Master S820E Maintenance Manual (10580-00345). Includes
general information on the instrument, test equipment required, a
replaceable parts list, and verification procedures including frequency
accuracy, return loss, and dynamic range.
These documents along with additional application notes and white papers
covering cable and antenna analysis are available on the documentation disc
included with the instrument and also from the Anritsu web site via the
Site Master S820E product page:
http://www.anritsu.com/en-us/products-solutions/products/S820E.aspx
Note
Anritsu recommends allowing the S820E to warm up for
10 minutes to typical operating temperature before calibrating.
The instrument will require a new calibration if the internal
instrument temperature changes more than ±10 ºC after
calibration.
