Marker Menu (Continued)
Key Sequence: Marker
Marker Search
Tracking (On Off): When turned On, the active marker
becomes a tracking marker and defaults to tracking the peak.
To track Valleys, press the Marker to Valley button after
turning on Tracking. The Search settings can all be applied
to a Marker with Tracking either On or Off.
Marker to Peak: Places the currently active marker on the
highest signal amplitude currently displayed on screen.
Marker to Valley: Places the currently active marker on the
lowest signal amplitude currently displayed on screen.
Markers 5, 6, 7, and 8 can perform a special Marker search
to find the Peak or Valley between two other markers.
When Marker 5 or Marker 7 is Active:
Peak Between M1 & M2: Places Marker 5 or 7 on the
highest signal amplitude between Marker 1 and Marker 2.
Valley Between M1 & M2: Places Marker 5 or 7 on the
lowest signal amplitude between Marker 1 and Marker 2.
When Marker 6 or Marker 8 is Active:
Peak Between M3 & M4: Places Marker 6 or 8 on the
highest signal amplitude between Marker 3 and Marker 4.
Valley Between M3 & M4: Places Marker 6 or 8 on the
lowest signal amplitude between Marker 3 and Marker 4.
Figure 3-43. Marker Menu (2 of 2)
