S820E UG PN: 10580-00343 Rev. H 1-5
General Information 1-4 Instrument Description
Battery Information
The battery that is supplied with the Site Master may need charging before
use. It can be charged using either the AC-DC Adapter or the DC adapter.
Refer to “Status Tool Bar” on page 2-19 for a description of battery symbols.
The batteries are typically charged in the instrument.
Refer to Chapter 12, “Battery Replacement” for additional information on
replacing the batteries.
Note
Use only Anritsu Company approved batteries, adapters, and
chargers with this instrument.
The batteries will charge at a faster rate when the instrument is
turned off or is set to standby mode. Charging the batteries while
the instrument is running requires a longer time to reach a full
charge.
To prolong the useful battery life, the internal charging circuit
monitors battery temperature. Normal charging occurs when the
battery temperature is between 0 °C and 45 °C. Charging is
paused if the internal battery temperature is beyond this range.
Caution
When using the Automotive power outlet adapter, always verify
that the supply is rated for a minimum of 60 Watts at 12 VDC, and
that the socket is clear of any dirt or debris. If the adapter plug
becomes hot to the touch during operation, then discontinue use
immediately.
Note
Anritsu Company recommends removing the battery for long-term
storage of the instrument.
