Anritsu S820E - Amplitude Menu

9-22 PN: 10580-00343 Rev. H S820E UG
9-7 Amplitude Menu High Accuracy Power Meter
9-7 Amplitude Menu
Key Sequence: Amplitude
Amplitude
Max Value: Sets the maximum value on the display in dBm
or Watts.
Min Value: Sets the minimum value on the display in dBm
or Watts.
Offset Value: Used to set external power attenuation or
gain. The displayed power level is offset by the dB value
entered.
Relative On Off: Press this submenu key to toggle relative
power On or Off. This measurement shows the relative level
of the current power level to the level when relative was
turned on. When ON, the message Relative On shows in the
message area.
Units dBm Watts: Sets the unit of measure for the power
meter.
Autoscale: Adjusts the Top and Bottom values so that the
power meter needle will be shown in the middle of the analog
display.
Fullscale: Adjusts the Top and Bottom values to their
maximum allowed values (default settings).
Figure 9-17. High Accuracy Power Meter Amplitude Menu
Amplitude
Max Value
Min Value
Autoscale
Amplitude
Relative
Re
la
ti
ve
On O
Fullscale
Oset Value
Units
A
uto
sc
al
e
U
ni
ts
dBm Watts
