Anritsu S820E - Trace Menu

S820E UG PN: 10580-00343 Rev. H 3-69
Cable and Antenna Measurements 3-19 Trace Menu
3-19 Trace Menu
Key Sequence: Trace (5)
Trace
Copy Trace to Display Memory: Copies the current
trace display to memory for use in Trace Math and Trace
Display options.
Trace Display: Press to change the display options.
Trace Only: The active trace is shown (yellow).
Memory Only: The trace stored in memory is
displayed in purple.
Trace & Memory: Displays both the stored trace
(purple) if a trace is stored in memory and the
current active trace (yellow).
Trace Math: Press to change the trace math options.
None: The active trace is shown as is, with no
math functions.
Trace – Mem: Displays the difference between
the active trace and the trace in memory.
Trace + Mem: Displays the results of logarithmic
adding of the active trace and the trace in memory.
(Trc + Mem) / 2: Displays the results of the
average of the active trace and trace in memory.
Figure 3-49. Trace Menu
Trace Display
Trace Only
Trace D
Trace
O
Trace &
Memory
Memory Only
Trace Math
None
Tr
ac
No
n
Trace - Mem
Trace + Mem
(Trc + Mem) / 2
Copy Trace To
Memory
