11-10 PN: 10580-00343 Rev. H S820E UG
11-5 Updating the Site Master Firmware System Operations
11-5 Updating the Site Master Firmware
The Site Master firmware is updated using a customer supplied USB memory
stick. The firmware update is downloaded from the Anritsu web site.
Updated product information can be found on the Anritsu web site:
http://www.anritsu.com/
Search for the product model number. The firmware updates are on the
product page under the Library tab in the “Drivers, Software Downloads”
section.
1. Click on the “Firmware Update for the Site Master S820E” link.
2. Click the “Download” button and then “Run”. After the download is
complete, press “Run” again and follow the onscreen instructions.
Press “Help (?)” for additional information.
3. After the firmware update is saved on the USB memory stick, remove
the memory stick from the computer.
4. Turn off the Site Master and insert the USB memory stick into the USB
port.
5. Connect the AC adapter and turn the Site Master on.
6. Press the Preset (1) key.
Note
Press the Anritsu logo in the upper-left corner of the screen to
display instrument status. Press SW Info button to view the
current software revision. Instrument status can also be found in
the System menu.
Note
The “Release History” link provides a summary of the firmware
changes.
