Anritsu S820E - Freq;Dist Menu (Continued)

S820E UG PN: 10580-00343 Rev. H 3-59
Cable and Antenna Measurements 3-11 Freq/Dist Menu
Freq/Dist Menu (Continued)
Key Sequence: Freq/Dist
DTF Setup
Cable List: The Cable List submenu key opens a list of
available cable specifications (Figure 3-6). Using Up/Down
Arrow keys, the rotary knob, or the touchscreen, select the
desired cable and press Enter.
Note: When a cable is selected from this list, propagation
velocity and cable loss are automatically set by the
instrument. If the preselected values for propagation velocity
or cable loss are changed, then the analyzer will use “NONE”
as the cable type.
Cable Loss: Press the Cable Loss submenu key and enter
the loss in dB/ft or dB/m for the selected cable using the
keypad, Up/Down Arrow keys, or the rotary knob and press
Enter.
Prop Velocity: Press the Prop Velocity submenu key and
enter the applicable propagation velocity for the selected
cable using the keypad, Up/Down Arrow keys, or the rotary
knob and press Enter.
Windowing: Opens the “Windowing Menu” on page 3-60.
Figure 3-38. Frequency/Distance Menu (2 of 2)
Cable List
Cable Loss
DTF Setup
Prop Velocity
Windowing
