9-12 Display Setup Menu High Accuracy Power Meter
Forward Menu
Key Sequence: Display Setup > Forward
Forward
Average Power: Press this submenu key to have the
sensor measure the average power in the forward direction.
Crest Factor: Press this submenu key to have the sensor
measure the Crest Factor in the forward direction. Crest
Factor is a ratio of peak power to RMS power.
Burst Average Manual: Press this submenu key to have
the sensor measure the average power within the signal
bursts (in the forward direction). You define the duty cycle of
the bursts in order to complete the averaging calculation.
Burst Average Auto: Press this submenu key to have the
sensor measure the average power within the signal bursts
(in the forward direction). In auto, the sensor determines the
duty cycle of the bursts in order to complete the averaging
calculation.
Peak Envelope Power: Press this submenu key to have
the sensor measure the peak power in the forward direction.
CCDF: Press this submenu key to have the sensor measure
the value of the Complementary Cumulative Distribution
Function (CCDF). The CCDF describes the probability that
the signal power is greater than a threshold value.
Figure 9-23. High Accuracy PM (MA24105A) Forward Menu
Display Setup
Forward
Average
Power
rw
r
Aver
Crest Factor
Burst Average
Manual
Burst Average
Auto
Peak Envelope
Power
CCDF
To Next Page
