Instrument Overview 2-4 Front Panel Overview
LED Indicators
Power LED
The Power LED is solid green when the instrument is on, and slowly pulses
when the Site Master is in standby mode.
Charge LED
The LED is green when the Site Master is on and the battery is fully charged.
The LED is orange when the battery is charging, and is off when the
Site Master has no external power.
Press the battery icon at the top of the screen to view the current
battery charge.
