Chapter 5 — Classic Mode Operation
5-1 Introduction
The Site Master S820E provides a “Classic” Cable and Antenna Analyzer
measurement mode which emulates the user interface from the Anritsu
Site Master ‘D’ series of instruments. This emulation is intended to help
users of the S820E follow existing carrier Method of Procedure (MOP)
documents that specify an earlier Site Master model.
To provide quick and easy familiarity with the Site Master user interface,
many of the advanced features such as Dual Screen display, Smith Chart,
Phase, and multi-segmented limits, are purposely removed while in Classic
Mode. Please switch to Advanced Mode to access these useful features when
desired.
Refer to Figure 5-1 on page 5-2 for a comparison of Site Master S820E
“Classic” vs. “Advanced” Cable & Antenna modes.
Refer to Chapter 3, “Cable and Antenna Measurements” for a complete
overview of the instrument GUI. This chapter summarizes the differences
between “Classic” mode and the “Advanced” S820E Cable and Antenna mode.
Note
Use the Menu key and confirm that the instrument is in “Classic”
Cable-Antenna Analyzer mode before continuing.
Classic Mode is always displayed above the measurement type
when the instrument is in “Classic” mode.
Note
Screen images in this User Guide are illustrations of typical
instrument features. Some images may include instruments other
than the Site Master S820E. Traces and other display features
may differ from the screen displays of your instrument.
