S820E UG PN: 10580-00343 Rev. H 3-1
Chapter 3 — Cable and Antenna
Measurements
3-1 Introduction
This chapter provides an overview of Cable and Antenna measurements and
how to set up the instrument and perform basic line sweeps.
Figure 3-1 illustrates a typical Cable and Antenna Return Loss
measurement.
Note
Use the Menu key and confirm that the instrument is in
Cable-Antenna Analyzer Advanced mode (not Classic mode). In
Classic mode, Classic Mode is clearly displayed at the top of the
instrument screen in the System Function Tool Bar.
Note
Screen images in this User Guide are illustrations of typical
instrument features. Some images may include instruments other
than the Site Master S820E. Traces and other display features
may differ from the screen displays of your instrument.
