3-2 PN: 10580-00343 Rev. H S820E UG
3-1 Introduction Cable and Antenna Measurements
1. Active Trace (Yellow)
2. Limit Line (Green when Passing)
3. Marker 2 (Marker to Peak)
4. Measurement Type
5. Stop Frequency (F2)
6. Pass Message (Active trace is below the limit line in Return Loss
measurement)
7. Marker 1 (Marker to Valley)
8. Marker Table
9. Start Frequency
10. Measurement Details (also Menu Shortcuts)
11. User-defined Setup and Menu Shortcuts (not available in Classic mode)
Figure 3-1. Cable and Antenna Display Overview
2
3
4
1
10
11
6
8 7
9
5
