1-10 PN: 10580-00343 Rev. H S820E UG
1-10 Tilt Bail Stand General Information
1-10 Tilt Bail Stand
A Tilt Bail is attached to the back of the Site Master for desktop operation.
The tilt bail provides two settings of backward tilt for improved stability. To
deploy the tilt bail, pull the bottom of the tilt bail away from the back of the
instrument. To store the tilt bail, push the bottom of the bail towards the
back of the instrument until it attaches to the Site Master.
1-11 Anritsu Service Centers
For the latest service and sales information in your area, please visit the
following URL:
http://www.anritsu.com/Contact.asp
and choose a country for regional contact information.
Note
Do not use the tilt bail while the instrument is in the soft case. The
soft case has an adjustable tilt bail panel in the back zipper.
Figure 1-2. Tilt Bail Extended (different model shown)
