S820E UG PN: 10580-00343 Rev. H 6-1
Chapter 6 — VNA Mode
6-1 Introduction
This chapter provides an overview of VNA Mode (Vector Network Analyzer
mode, Option 440) measurements.
Figure 6-1 on page 6-2 illustrates a typical VNA Mode display screen.
Note
Use the Menu key and confirm that the instrument is in Vector
Network Analyzer mode.
Note
Screen images in this User Guide are illustrations of typical
instrument features. Some images may include instruments other
than the Site Master S820E. Traces and other display features
may differ from the screen displays of your instrument.
