S820E UG PN: 10580-00343 Rev. H 1-3
General Information 1-4 Instrument Description
The internal memory is large enough to store more than 2,000 files. Files can
be any combination of measurement files, setup files, or screen shots. Files
can also be saved or copied to a connected USB flash drive. Measurements
can be transferred to a PC using the supplied USB cable or with a USB flash
drive.
The use of folders (with no more than 300 files per folder) is advisable when
storing a large number of files within the Site Master internal memory. When
navigating through folders with larger numbers of files, the sorting process
can take noticeably longer and can delay the display of those files.
Included with the S820E is Line Sweep Tools (LST), a PC-based software
program than can be used to create reports, view and organize data, analyze
historical data, edit markers and limit lines, rename traces, and trace
analysis. Refer to Chapter 13 for a brief overview of Line Sweep Tools.
Anritsu easyTest Tools provides a library of commands and a drag-and-drop
interface for creating test sequences. The Windows XP, Windows Vista, and
Windows 7 compatible software is available on the Anritsu web site.
• A developer creates an easyTest test sequence (.ett) file on a PC. The
file is copied to the S820E using a USB flash drive.
• When the file is run using the easyTest icon on the Menu Shortcut
screen, the S820E displays instructions one step at a time to the
operator, simplifying the process of operating the instrument and
completing assigned tasks.
easyTest Tools Help (which includes a Quick Start Topic), full use
instructions, and sample .ett files are included on the disc with the
software. After installing easyTest Tools on a PC, start the application and
choose Help for additional information.
Refer to Chapter 14 for a brief overview of easyTest Tools.
